CIBES AIR®
The Cibes Air has an exquisitely elegant design, offering you a unique user experience where form and function work together to guide your senses.
A space-saving lift solution, which is much faster and easier to install than a conventional lift. The great choice of colours and materials makes it easy to tailor the design of the Cibes Air to your taste and unique sense of style.
Main features:
- Design with wood, fabric and metal
- Close to 300 different colours
- Lift shaft with panoramic glazing
| Installation | Indoor |
| Rated load | 300/400/500 kg |
| Power supply | 1x230 V a.c./ 3x 230 V a.c. / 3x400 V a.c., 50 Hz, 16 A, 3x2,5 mm2 |
| Speed | Max. 0.15 m/s |
| Top height | 2250/1300 mm |
| Min. headroom | 2300 mm (door) |
| Pit depth | 0/50/70 mm |
| Directives&standards | MD 2006/42/EC, EN 81-41, SIL3 |
| Drive system | Screw and nut |
| Lift controls | Hold-to-run on platform, one touch on landings |
| Control system | Micro computer based SIL3 |
| Power motor | 2,2 kW |
| Machine room | Machine room less (MRL) |
| Max. number of stops | 6 |
| Max. travel | 13 m |
| Door configuration | Single hinged doors (L/R), single entry, open-through or adjacent access |
| Safety | Safety edges for the top of the platform and floor, overload protection, emergency stop and alarm button, telephone and battery emergency lowering are included as standard, various lock solutions and fire drive are available as options. |
| Lift shaft | Tempered and laminated safety glass (4.0 mm + 0.76 mm PVB foil + 4.0 mm) or steel panels. |
